Standard Specifications
HULL
Deep "V" Planing hull design
14° deadrise at the transom, 23° deadrise amidships.
ISO NPG white gelcoat w/vinylester backup resin.
Bottom, topsides and transom VIP resin infused biaxial E-glasswith Corecell SAN foam core.
Stringer system biaxial E-glass with foam core.
Resin Infused E-glass swim platform with the molded-in anti-skidsurtace.
Hull side rubbing strakes.
White PVC rub rail with stainless steel cap.
Painted (Urethane) double boot top. - Gold recessed cove stripe.
DECK AND HARDTOP
ISO NPG Gelcoat
VIP resin infused biaxial E-glass with balsa core.
Molded-in anti-skid deck surfaces.
Companionway door to port.
Sliding windows in the salon on cabin sides.
Electric opening window in salon aft bulkhead.
Hinged access door to side deck at the helm.
Flush, outward opening, transom door with latch
Anchor locker with slam latch.
Large lazarette/engine room access hatch in cockpit sole withcompression latches.
Integrated Sure Shade system over cockpit
DECK HARDWARE
1 1/4" Diameter type 316 stainless steel perimeter rail system.
(6) 12 Stainless steel cleats: two forward four mid ship.
(2) Stainless steel bollard cleats aft
(2) Stainless 12" cleats on cockpit coaming on centerline
(1) 10"Stainless steel cleat to starboard of windlass as anchor rodetie off.
(4) Custom cast stainless steel mid-rail line chocks.
(2) Custom cast stainless steel skene chocks forward.
Custom stainless steel bow pulpit with dual anchor roller forCQR or Delta anchor and "lunch hook."
Ouick anchor windlass, electric rope-chain type.
Teak flag staff and socket on taffrail.
Burgee staff on the bowpulpit
(6) Low Profile stainless steel hatches w/screens.
(6) Custom stainless steel opening port lights.
Teak toe rails.
Teak cabin-side eyebrow.
Teak table in cockpit
Custom cast stainless steel "SABRE" logo.
Raw water wash down system at the bow.
HELM STATION
Hinged access door to starboard side deck.
Dual Volvo-Garmin 8617 Multi-Function Displays (MFDs) w/Separate SD Card Readers.
Volvo-Penta Autopilot w/ Joystick Driving.
Volvo-Penta IPS Plus Joystick Controller on Stidd Armrest.
Twin Lever Shift & Throttle Control (EVC-E) w/ Single Lever &Cruise Control Software.
Triple windshield wipers w/ multiplespeed settings.
Windshield washers plumbed from the fresh water system.
Ritchie Compass.
Switch controls for horn, running lights, anchor light, engine roomblowers, & bilge pumps.
Custom teak steering wheel w/ tilt helm &Sabre logo.
Twin Stidd N Series helm seats mounted on a cherry cabinet
NMEA 2000 backbone
PROPULSION
Twin Volvo-Penta IPS 700 inboard propulsion system, electric shift transmissions & NiBrAl P-series duo-props -Tier III emission certified.
Pleasure craft rated VP D8, 550mhp @, 2900rpm engines.
Integrated fresh water heat exchanger cooling system.
24v-110Amp alternator each engine.
Extra 12v-115 Amp alternator.
Volvo-Penta 900mm Interceptor trim system w/ auto trim.
Dynamic Positioning System (DPS).
Active Corrosion Protection system (ACP).
Volvo-Penta Clear Wake Exhaust bypass system (EVC controlled).
Groco raw water intake strainers & safety sea valves.
Engine room blower & vent ducts.
Engine room floor with FRP anti-skid.
Gloss white engine room.
Gloss white painted engines.
Mylar-faced foam noise barrier.
FUEL SYSTEM
(2) 263 USG diesel fuel tanks port and starboard.
Dual Racor fuel filters
(2) 2" "Diesel" deck fill plates.
12V DC ELECTRICAL SYSTEM
(4) AGM Group 31 dedicated engine start batteries.
(3) AGM 4D deep cycle ship's service batteries.
(1) AGM Group 24 generator start battery.
Remote control battery switches with controls at helm.
Manual emergency battery crossover switch.
Illuminated main circuit breaker distribution.
Digital battery monitor.
Lighting:St. Maarten amber cabin reading lights.High output LED lights in the overhead. LED strip lighting in appropriate locations.LED engine room lighting.
Tri-color lights over helm station, red, white blue Cockpit courtesy lights.
Marine-grade, tinned wire throughout.
12V DC USB chargers at helm and in all cabins
120V AC Electrical System
Onan 13.5 kW generator including:
Onan E series display
Dedicated start battery.
Water drop muffler.
Cooling water intake strainer. Sound shield.
Transfer switch.
50A shore power service with Glendinning Cablemaster & 70ft. cord.
Isolation transformer
Illuminated main circuit breaker distribution panel.
Digital AC system monitor
120V GFCI protected outlets in each cabin and engine room.
50amp, 3-bank battery charger
Reverse cycle heat/air conditioning with 4 zones.
-One 10k BTU inthe forward cabin,
-One 10k BTU in the master cabin
- One 16k BTU in the galley
- One 24k BTU in the main salon.
MASTER STATEROOM
Island berth athwartship layout with 9" foam mattress andaminated trim.
Hull side deadlight over head board
Shoji style passageway and closet doors
Shoji style portlight screen panels
Cherry hull ceilings.
Drawers under berth and in bulkhead aft of berth.
(2) hanging lockers fore and aft of bed
Teak and holly sole.
Sound deadening soft headliner panels.
Sliding door to master head compartment.
MASTER HEAD
Private access from master stateroom
Custom tile in WC and shower sole
High gloss finish over the solid cherry counter.
Vanity cabinet below sink - Storage outboard
Mirror above vanity, cherry framed
Separate shower stall with clear bi-fold enclosure and glass tileaccent wall within
Electric shower sump pump
Opening port to side deck
Deck hatch with blind/screen overhead
Ventilation blower
Stainless steel towel bars
VIP/FORWARD STATEROOM
Spacious island berth, with 6" mattress and laminated trim.
Cherry hull ceilings.
Drawers under berth, A/C return grille beside.
Storage lockers, drawers, and shelves.
Teak and holly sole.
Sound deadening soft headliner panels
Private access to the forward head and shower
VIP/FORWARD HEAD
Stainless steel under mount sink.
Shower stall with seat and locker outboard.
Hot and cold pressure water
Electric shower sump pump.
Storage lockers.
Solid surface vanity top with bull nose.
Towel bars
Soap dispenser
Cherry wood trimmed mirror over the sink.
Ventilation blower.
GALLEY
Solid surface counter top.
Stainless steel under mount sink with cover and pull-out faucet
Soap dispenser
Isotherm stainless steel stand-up refrigerator (top) and freezer
Touch control induction cooktop
Convection microwave with stainless steel face
Drawers and storage lockers below the counter.
Built-in waste basket.
Recycle bin below steps.
