Descriptions

Steering System
Joystick Control

Factory Options & Custom Factory Options

MECHANICAL

Seakeeper NG16 gyro stabilizer
Shore water inlet connection aft

ELECTRICAL

Central vac with (2) outlets and 32 foot hose
Power height/fore/aft helm seats w/ chrome package
Bow shore power cords 2 x 25 feet
Install parallel NMEA backbone system.
Electric Ocean Air blinds on the 3 forward windshield w/ a remote control. Fabric Chintz Topar Plus. 418-0204

EXTERIOR & DECK

Contrasting non-skid color
Teak decking in aft cockpit and steps
Teak decking on swim platform
Storage for (2) 8 person manually deployed liferafts one fwd and one aft in cockpit seating
In forward fender locker add step inside the well for easy access
Upgrade hydraulic swim platform to 2200lb capacity
Ship (1) Joystick control mount only for the cockpit. Ship loose on boat. Dealer to supply and install mounts, Joystick and controls.
In forward fender locker install a hose reel for washdown hose
Custom Perennials, Sail Cloth, Ash #681-108 no repeat - solid in the cockpit on the settee and chairs
Custom electronics mast arrangement. Increase size of radar platform to fit 6" Garmin opem array. Platform above to fit 24" dome radar. Small platform above it for a spotlight on top, with hailer under it FLIR mounted on top of mast.
Build storage for tanks and cleaning supplies in the transom locker.

INTERIOR

Install the standard manual blinds on the port side, starboard side and aft door. Share color Chintz Topar Plus

MEZZANINE DECK / MAIN SALON / HELM DECK

Mezzanine deck sole to be teak decking. No finish on teak decking
Main salon sole, 3.5'' cherry bead board with no border
Helm deck sole materials Cherry bead board 3.5'' in 14' lengths with no seam in the sole.
Increase the height of the helm deck settee 3".
Install throttle/shift control in the standard location
Mezzanine deck counter top Bianco Rhino Marble in lieu of standard
Add S48 style arm rests to the main salon settee. ARm est to stand 6'' above the seat cushion
Custom Perennials, Ritzy, Chalk #978-224 textured fabric on the main salon settee and standard chairs
Custom Great Outdoors (Helly Hunt), Beach Blanket, Beta Blue #120/06 no repeat - solid on the helm deck settee

GALLEY

Galley counter Bianco Rhino Marble

MASTER STATEROOM & MASTER HEAD

Walk in closet with storage
Main salon sole, 3.5'' cherry bead board with Cherry border in 14' lengths
In Master Head install 1 large mirror covering the aft bulkhead with lights in the overhead panel
Install a U/L Promessa Bronze panel above the Master Stateroom steps
Master head, custom flat front vanity with two (2) semi-recessed sinks (same as the 54 day head) and custom stainless steel rail
Replace MSR head cherry staving with Sport Yacht White FRP head staving like DE37
Ona Blanco NP 13''x40'' on the port bulkhead tiled in horizontal pattern. Madagascar tile on aft, fwd and stbd walls, White Grout
Tile in master head and master shwoer sole to be SPM 7030 Penny Rounds with warm gray grout.
Custom Great Outdoors (Helly Hunt), Libre, Playa #219-02 in the master stateroom settee
Add S48 style arm rests on the master stateroom settee. Same arm rest height as EE001

VIP STATEROOM & HEAD

In the VIP head delete the vessel sink and install semi recessed sink like the 54 day head
In the VIP shower install weave pattern, Atlas Concorde 3D Grid White Glossy, tiled vertically on the on the fwd bulkhead. Outboard, aft and inboard bulkhead to be Polar Fine large glossy white tile without a pattern. White grou
In the guest shower sole SPM 7030 Penny Rounds with warm gray grout

GUEST CABIN & HEAD

In the Guest head delete the vessel sink and semi-recessed sink like the 54 day head. This design change requires a custom grab rail.
In the guest shower install weave pattern, Atlas Concorde 3D Grid White Glossy, tiled vertically on the on the aft bulkhead. Outboard, fwd and inboard bulkhead to be Polar Fine large glossy white tile without a pattern. White grout.
In the guest shower sole SPM 7030 Penny Rounds with warm gray grout
Custom Great Outdoors (Helly Hunt), Libre, Playa #219-02 on the guest cabin scissor berth

Electronics

(2) Garmin GGM 190 Touchscreen
(2) Garmin 8530 Black Boxes
(2) Garmin Grid
(1) Garmin 8215 to match the existing 15''
(2) Garmin Data Card Readers
(2) Garmin GPS Antennas
GMR 626 xHD2 6' Open Array
Garmin GMS10 Network Port Expander
NMEA 2000 Starter Kits
(1) 4' VHF Antenna with ratchet mount
Airmar Weather STation
Airmar NMEA 2000 Sensor Cable
(3) Garmin GC10 Camera
(2) 8' VHF with ratchet
Garmin GSD 25 Premium Sonar Module
Airmar Depth/Temp Transducer
Airmar DT800 Titled Element Transducer
Garmin WIFI Adaptor
Garmin GXM 52 Sirius Weather Receiver
Garmin AIS600 Class B AIS Transceiver
(1) Intellian S6 HD US Ku Ka Band
(1) Dummy Dome
(4) DirectTV H25 Receivers
(4) RF Remote Controls
Fusion Stereo System
(3) Wired remotes
2 Channel Amp Speakers
SAT Radio Antenna and Cable
ACR RCL 3000 HID Remote Spotlight
Hailer
All Hardtop Equipment painted to match superstructure color

Decor

EXTERIOR

Hull Paint Color: Sea Goddess Yellow - Dupont Match
Boot Top Color: Claret Red
Deck Color (Gelcoat): Sabre White
Anti Skid Color (Gelcoat): Beige
Swim Platform Color & Anti Skid: Sabre White w/ Teak
Cockpit Settee Fabric: Perennials, Sail Cloth Ash, no repeat solid

MEZZANINE DECK / MAIN SALON / HELM DECK

Overhead Cloud Fabric: U/F Primera Chalk
Mezzanine Countertop Color: Bianco Rhino Marble
Mezzanine Deck Sole Material: Teak Decking
Main Salon Settee Fabric: Perennials Ritzy Chalk, Textured w/ Sabre 48 Style Arm Rests that stand 6'' above the seat cushion
Main Salon Chairs Fabric: Perennials, Ritzy Chalk, Textured
Main Salon Cabin Sole Material: Cherry bead board 3.5'' in 14' lengths. No seam or border in/around sole
STIDD Seat Fabric: Ultraleather Pony Marengo
Helm Deck Settee Fabric: Great Outdoors Helly Hunt Beach Blanket, Beta Blue, no repeat solid.
Helm Deck Sole Material: Cherry bead board with no seam in the sole.
Ocean Air Blind Color: Chintz Topar Plus 418-0204

GALLEY / HALL

Galley Countertop Material: Bianco Rhino Marble
Galley Sole Material: Cherry and Holly
Art Nook Material: STD High Gloss Cherry
Hallway Covering Material: Vinyl Thai Silk - Tropic Taupe 7593
Hallway Sole Material: Cherry and Holly

MASTER STATEROOM & MASTER HEAD

Master Settee Fabric: Perennials, Ritzy Chalk, Textured w/ Sabre 48 style arm rests that stand 3/4'' above the seat cushion
Master Wall Covering Material: Vinyl Thai Silk - Tropic Taupe 7593
Master Sole Material: Cherry bead board 3.5'' in 14' lengths. No seam in cabin sole
Master Head Countertop Material: Glacier White Corian
Master Head Sole Material: SPM 7030 Penny Rounds with warm gray grout
Master Shower Wall Tile: Ona Blanco NP 13"X40" on the port bulkhead tiled in horizontal pattern. Madagascar tile on aft, fwd and stbd walls. White grout
Master Shower Sole Tile: SPM 7030 Penny Rounds with warm gray grout

VIP STATEROOM & HEAD

VIP Wall Coverings: Vinyl Thai Silk - Tropic Taupe 7593
VIP Cabin Sole Material: Cherry and Holly
VIP Head Countertop: High Gloss Cherry with standard vessel sink
VIP Head Sole Material: Cherry and Holly
VIP Shower Wall Tile: Atlas Concorde 3D Grid White Glossy, tiled vertically on the on the fwd bulkhead. Outboard, aft and inboard bulkhead to be Polar Fine large glossy white tile without a pattern. White grout
VIP Shower Sole Tile: SPM 7030 Penny Rounds with warm gray grout

GUEST STATEROOM & DAY HEAD

Guest Sole Material: Cherry and Holly
Day Head Sole Material: High Gloss Cherry with standard vessel sink
Guest Shower Wall Tile: Atlas Concorde 3D Grid White Glossy, tiled vertically on the on the aft bulkhead. Outboard, fwd and inboard bulkhead to be Polar Fine large glossy white tile without a pattern. White grout
Guest Shower Sole Tile: SPM 7030 Penny Rounds with warm gray grout

Additional Equipment

CANVAS

Custom Canvas-Aft Cockpit Seat Covers
Custom Canvas-Aft Cockpit Chair Covers
Custom Canvas-Stern Flag Cover and Burgee Cover

Standard Factory Specifications

PROPULSION SYSTEM

(2) Volvo IPS 1200 drives w/D13 900hp engines
Volvo Interceptor automatic trim system
Volvo DPS positioning system
Volvo Active Corrosion Protection system
Volvo autopilot with joystick steering
Volvo/Garmin Glass Cockpit Engine Display (1)
Fresh water-cooled engines
Primary 24VDC alternators each engine for charging isolated engine start batteries
Groco raw water intake strainers
Oil change system services engines, drive units, and both generators
Engine room ventilation system 24VDC
Engine room intake ducts on cabin house side with stainless steel grills
White gelcoated engine room
Fully sound insulated engine room

HULL

Premium LP Painted Topcoat Finish
Modified "V" planing hull design
21 degree deadrise amidships and 16 degree deadrise at transom
Reverse sloped transom
ISO NPG clear gel coat w/ vinylester back-up resin
Knitted Biaxial Structural E-Glass reinforcements
Infused SAN Corecell foam core in hull bottom and topsides
PVC Foam cored composite stringer system
Hull side rubbing strakes
PVC rub rail with stainless steel cap
Painted (Urethane) Double Boot Strip
Gold Cove Stripe

DECK

ISO NPG gelcoat
VIP resin infused Knitted Biaxial Structural
E-Glass Reinforcements with coring
Molded-in anti-skid deck surfaces
Twin anchor lockers
Direct glazed windshield
Sliding/opening side windows
Port & Starboard transom gate access to cockpit
Cockpit U-shaped settee with hi gloss table & (2) chairs
Hydraulic submersible swim platform 900 lb. capacity for dinghy storage and handling

DECK HARDWARE

1 1/2" diameter type 316 stainless steel perimeter rail system
(4) stainless steel spring cleats
(2) stainless steel mooring cleats
(2) stainless steel stern cleats
Salt water wash down system forward
Custom stainless steel dual anchor roller
24V Electric Windlass with controls at helm and foot switches on deck
Flagpole holder and flagstaff
Stainless steel hatches w/screens
Oversized Stainless steel opening ports
Teak cap rails port and starboard
Teak cabin side eye-brow
Custom cast stainless steel "SABRE" medallion
Triple Exalto windshield wiper systems
Dual Kahlenberg air horns
Cockpit retractable sun awning

FUEL SYSTEM

975 gal. diesel fuel total
Port & Stbd 225 gal. "day" tanks
525 gal. centerline diesel storage tank
Dual redundant fuel transfer pumps
Racor dual 75/1000MAX fuel filters for propulsion engines
Racor 500MA fuel filters for generators
2" "Diesel" stainless steel deck fill plates starboard

NMEA2000 NETWORK SYSTEM

Network monitoring of systems
Network control of DC & AC electrical circuits
Backup/override of all network circuit faults
Mode controls, single one push button activation of boat wide circuits, customizable
Onboard WiFi for network
(2) iPad Minis with Launch Port for wireless control of network systems

120/240 VAC ELECTRICAL

Twin 120/240VAC 50 amp AC shore power services with cord reels aft
Isolation boosting transformer each shore service
21.5kW Onan "Quiet" generator primary
13.5kW Onan "Quiet" generator secondary
Automatic AC switching system for shore & generator power
Mastervolt 4.0kW high output inverter/charger
Stand-alone 100A battery charger
All accessible 120VAC outlets GFCI protected
120/240VAC distribution panels in engine room, adjacent to helm, and in galley.

24DC ELECTRICAL SYSTEM

Ships battery bank (8) 6V AGM batteries
Port & starboard isolated 24VDC engine starting battery banks, (4) Lifeline AGM 3100
Dedicated 24VDC battery charger for engine battery banks
Helm remote controlled battery switches with manual override
LED Navigation lights
High efficiency LED designer lighting throughout interior
24VDC distribution panels in engine room, pump room, and adjacent to helm

12VDC ELECTRICAL SYSTEM

12VDC battery bank (2) Lifeline AGM 24 supports generator start & 12VDC circuits
Dedicated 12VDC battery charger
Redundant 24VDC/12VDC converter
12VDC USB outlets at helm and in all cabins
12VDC distribution panel adjacent helm

WASTE DISPOSAL

Polyethylene holding tank 120 gallon capacity
Holding tank vent filtration
Full time cycling pump room exhaust fan
Tecma Silence & Dometic Freshwater MSD's with white ceramic bowls
Diaphragm pump on holding tank to pump overboard
Electric motorized seavalve for holding tank pump out when at sea
Day head ability to bypass holding tank and direct overboard discharge via locked Y-valve

FRESH WATER SYSTEM

Water capacity approx. 300 gals.
24VDC Headhunter X-Caliber primary pump
240VAC Headhunter Mach 5 primary pump
26 gal. water heater
Hot water circulation pump
Filters on fresh water pump system and shore water inlet
Fresh water coil hose in engine room
Fresh water wash down at anchor locker

HELM DECK

Electrically operated sun roof over helm & salon
Twin Stidd helm seats with chrome finish
Joystick steering on helm seat armrest
Helm deck settee to port
Door to starboard side deck
Helm dash area finished in cherry
Volvo/Garmin touch screen display for network operation
Navigation switch panel
Custom wood trimmed stainless steel wheel
Air Conditioning/heat 12,000 BTU

MAIN SALON

U-shaped lounge to port with custom fabrics.
Hi-Lo table with inlays and deep epoxy finish
Lounge chairs to starboard with 50" HD Smart television on electric lift
Blinds on all windows
Cherry sole with sealer finish
Soft acoustic headliner panels
Air Conditioning/heat 48,000 BTU total,
24,000 BTU each side

BAR DECK

Stainless steel electric sliding double-acting door to cockpit with curved glass windows on corners
Designer countertop with bar sink and glass locker below
Sub-Zero undercounter refrigerator
Undercounter wine locker
Undercounter icemaker

GUEST STATEROOM- Forward

Scissor berth converts from queen island to twin bunks with storage below
Cherry hull ceilings
Enclosed upper shelves to port and starboard of island berth Fwd most section open shelf
Dimmable accent lighting below shelves and berth.
Cedar lined hanging lockers
Bureau
Built in 24"HD television
Screen/Shade for hatch
Private access to guest head/shower compartment
Cherry and holly sole with sealer
Soft acoustic headliner panels
Air Conditioning/heat 12,000 BTU

GUEST/DAY HEAD- Forward

High Gloss solid cherry vanity top with vessel sink and faucet
Cherry and holly sole with sealer in day head
Separate shower stall with ceramic tile floor
Storage lockers
Solid Surface Countertop
Stainless steel towel bars
Wood trimmed mirror over sink
Ventilation blower

VIP STATEROOM - To port

Queen island berth with drawer & storage below
Night stands with drawers both sides
Cedar lined hanging locker.
Bureau
Built in 32"HD television
Stainless steel investment cast port lights with screens
Round hull side deadlights
Screen/Shade for overhead hatch
Private access to VIP head
Cherry and holly sole with sealer
Soft acoustic headliner panels
Air Conditioning/heat 10,000 BTU

VIP HEAD

High Gloss solid cherry vanity top with vessel sink and faucet
Cherry and holly sole with sealer
Separate shower stall with ceramic tile sole
Ceramic tile floor
Storage lockers
Stainless steel towel bars
Wood trimmed mirror over sink
Ventilation blower

GALLEY

Toe kick space length of galley with courtesy lighting
Sub-Zero full height refrigerator/freezer
Wolf 4-element induction cook top
Wolf convection steam oven
Wolf microwave oven
Fisher & Paykel tall dish drawer
Galley exhaust fan 120VAC
Granite-cored counter top
Dovetailed drawers
Stainless steel under-mount sink with designer faucet
Pull out waste basket
Magic corner pull out storage
Air Conditioning/heat 10,000 BTU

UTILITY (between galley & master)

Stacked washer and dryer
Storage under stairs
Entertainment electronics locker

MASTER STATEROOM (Full beam)

King size island berth with drawers and storage below
Night stands with drawers both sides
Settee
Bureau(s)
Walk-in closet
Hanging lockers
Large fixed stainless steel hull port lights
40" HD Smart TV hidden in mirror
iPad Mini with Launch Port for wireless control of network systems
Cherry sole with sealer
Soft acoustic headliner panels
Air conditioning/heat 24,000 BTU

MASTER HEAD

Double vessel sinks with faucet
Solid Surface countertop
Cherry sole with sealer
Separate shower stall
Ceramic tile floor in shower
Storage lockers
Stainless steel towel bars
Wood trimmed mirror over sink
Ventilation blower

DÉCOR

Screens and shades on opening ports and hatches
Optional fabric and drapery selections
Optional custom décor packages available
Dovetailed maple drawer boxes throughout

SAFETY

Fire extinguishers throughout
Isolation transformers on shore power services
Bronze and Marlon sea valves on all below waterline fittings.
Bonding system to safeguard against galvanic corrosion
Automatic fire extinguishing discharge system with override
(4) Automatic electric bilge pumps 3700 GPH
(4) Bilge high water alarms

Manufacturer Provided Description

The Sabre 66 Dirigo is the first American built, downeast-style motor yacht of this size to be introduced to the market. She is, as Designer Kevin Burns states "the highest expression of Sabre yet." From her functional foredeck to her spacious and comfortable cockpit, she is every bit a Sabre. The best deck hardware, on-deck walking surfaces that are safe and secure, hand holds wherever they are needed, all speak to Sabre's 45 year history of building boats for people who know boats, and know how they should be equipped.

Her interior is crafted by boat builders with decades of experience. Her systems are modern and functional and her performance as invigorating as boaters have come to expect from Sabre Yachts. Her vee-hull with propeller pockets is sea-worthy and dry. As standard she is fitted with Caterpillar C15 865 hp electronic Acert engines, that are linked to Twin Disc Quick Shift transmissions for smooth and powerful operation. The 54 Salon Express will cruise comfortably in the mid-twenty knot range with incredibly low sound levels of 75 db. She is also available with Volvo IPS 900 engines and pods for those seeking the efficiency, convenience and close quarter's handling capabilities of pod drive systems. AC Electrical services aboard are provided by two 9.0 Kw Onan generators and her DC system is 24 volt. Molded steps from the aft cockpit provide easy access to her functional and well lit mechanical room.

Her interior accommodations are another world of comfort and elegance. Beautiful woodworking throughout the yacht, pleasing proportions and unusual fine points such as maple inlays and Shoji screens in the owner's cabin doors, all create an atmosphere of luxury and warmth in this masterpiece of the boat builders craft.

Disclaimer
The Company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.

Basic Information

Dimensions & Weight

Engine

Tank Capacities

Accommodations

External Links
